ALLNET SMB6615 Switch smart managed 15 porte Gigabit (13x RJ45 + 2x SFP) desktop/rackmount

The ALLNET SMB6615 is a smart managed switch offering 13 Gigabit RJ45 ports and 2 Gigabit SFP slots, designed for small to medium business networks requiring advanced management features without complexity. With a switching capacity of 30 Gbps and a fanless, silent design, it is ideal for office environments.

Advantages

Fanless operation ensures zero noise and lower power consumption (max 12W). The switch supports VLAN, QoS, link aggregation, and security features like port security and storm control. Its compact desktop form factor includes rackmount brackets for flexible deployment.

Suitable for

• Small and medium business networks
• Office environments requiring quiet operation
• Surveillance or IP camera systems (non-PoE)
• Edge or access layer switching

Key specifications

• 13 x 10/100/1000Base-T RJ45 ports
• 2 x 1000Base-X SFP slots
• Switching capacity: 30 Gbps
• Forwarding rate: 22.32 Mpps
• MAC address table: 8K entries
• Jumbo frame support: 9 KB
• VLAN: 802.1Q tag-based, port-based (up to 256 active VLANs)
• QoS: 802.1p CoS, DSCP, 4 priority queues
• Link aggregation: LACP, static trunk (up to 8 groups, 8 ports per group)
• Spanning Tree: STP (802.1D), RSTP (802.1w)
• Management: Web GUI, CLI (Telnet), SNMP v1/v2c/v3
• Security: Port security, storm control, DoS defense
• Power supply: Internal AC 100-240V, 50/60Hz
• Power consumption: max 12W
• Fanless design
• Mounting: Desktop, rackmount (brackets included)
• Dimensions: 280 x 180 x 44 mm
• Weight: 1.5 kg

Recommendations

For a reliable, quiet, and feature-rich smart managed switch, the ALLNET SMB6615 offers excellent value. Ideal for businesses needing VLAN segmentation and traffic prioritization without the cost of fully managed switches.
