Cavo FFC Lenovo 01YU976 per Lenovo Smart – connettore piatto flessibile per collegamenti interni

FFC cable Lenovo 01YU976 for Lenovo Smart is a flat flexible connector designed for internal signal and power routing between circuit boards and components. The cable reproduces the original internal layout to restore connections during repairs or replacements without changing the device’s external appearance. Made to fit Lenovo Smart series devices, it supports compact installations where space is limited and flexible routing is required.

Advantages

The flat construction allows tight bending radii and space-efficient routing inside slim housings, while the flexible substrate reduces stress on solder joints and connectors. It is compatible with the original connector pitch and contact arrangement, ensuring reliable electrical contact and consistent signal transmission. The thin profile preserves internal clearance and maintains the original mechanical layout of the device.

Suitable for

• Repairing internal connections in Lenovo Smart devices
• Replacing damaged or worn internal flex cables
• Restoring signal and power links between PCBs and modules
• Compact electronics assemblies where a low-profile flexible connector is required

Key specifications

• Connector type: flat flexible cable (FFC)
• Form factor: thin, flat ribbon for internal mounting
• Function: signal and power routing between circuit boards/components
• Mechanical characteristics: flexible substrate for small bend radius and low-profile installation
• Compatibility: designed for Lenovo Smart series internal connectors

How to use

Power off the device and disconnect from mains before opening the housing. Locate the connector on the mainboard and the mating socket; unlock any retaining latch on the socket, carefully extract the old cable if present, and insert the new flat cable with the correct orientation of the contacts. Ensure the cable is fully seated and lock the socket latch. Reassemble the device and verify functionality before final closure. Follow static discharge precautions and use appropriate tools to avoid damaging neighboring components.

Recommendations

Handle the cable by its reinforced ends where possible, avoid repeated sharp bends, and do not apply adhesive directly over contact areas. Use ESD-safe workspace and tools when performing installation or repair.
