CELLFAST GENERAL PURPOSE HOSE 16.0x3.5 30m REINFORCED

The CELLFAST General Purpose Hose is a reinforced PVC hose designed for a wide range of applications including water, air, light chemicals, gardening, and industrial use. With an outer diameter of 16.0 mm, wall thickness of 3.5 mm, and a length of 30 meters, this hose offers excellent flexibility and durability. It features high-strength polyester yarn braiding for reinforcement, ensuring a working pressure of 15 bar and burst pressure of 45 bar. The hose is UV resistant, abrasion resistant, and has good chemical resistance against dilute acids, alkalis, and common chemicals. It is REACH compliant and operates in temperatures from -10°C to +60°C.

Advantages

This hose combines high flexibility with robust reinforcement, making it easy to handle while maintaining structural integrity under pressure. Its transparent design with yellow/white reinforcement allows for easy visual monitoring of flow. The 3-layer construction (inner PVC, polyester reinforcement, outer PVC) provides excellent durability and longevity.

Suitable for

• Water supply and distribution
• Compressed air systems
• Light chemical transfer
• Gardening and irrigation
• Industrial applications

Key specifications

• Inner Diameter: 9.0 mm
• Outer Diameter: 16.0 mm
• Wall Thickness: 3.5 mm
• Length: 30 m
• Working Pressure: 15 bar (217 PSI)
• Burst Pressure: 45 bar (652 PSI)
• Temperature Range: -10°C to +60°C (14°F to 140°F)
• Material: PVC with Polyester Yarn Reinforcement
• Color: Transparent with Yellow/White Reinforcement

Recommendations

For optimal performance, ensure the hose is used within the specified pressure and temperature limits. Avoid exposure to sharp objects and extreme chemicals. Store in a cool, dry place when not in use.
