Dahua IPC-HFW1839TC-A-IL-0360B Telecamera IP, 3,6 mm

The Dahua IPC-HFW1839TC-A-IL-0360B is an IP camera with an 8 MP CMOS sensor that delivers 3840 × 2160 resolution at up to 20 fps and 2688 × 1520 at up to 30 fps. It features H.265 compression, built-in IR illumination with a range of up to 30 m, and a built-in microphone for audio recording.

Key features

• 8 MP CMOS sensor
• H.265 compression, Smart H.265+/H.264+
• Built-in IR illumination up to 30 m; warm light up to 20 m
• Built-in microphone
• IP67 protection
• Person detection
• 12 VDC/PoE power
• Starlight low-light sensitivity
• Image functions: rotation mode, DWDR, 3D NR, HLC, BLC, watermarking
• ROI (4 areas)
• Intelligent search with Smart NVR

Specifications

• Model: IPC-HFW1839TC-A-IL-0360B
• Brand: Dahua
• Image sensor: 8 MP CMOS
• Resolution: 8 MP (3840 × 2160) @20 fps; 2688 × 1520 @25/30 fps
• Video compression: H.265; H.264; H.264H; H.264B; MJPEG (secondary stream only)
• Smart compression: Smart H.265+; Smart H.264+
• Number of streams: 2
• Frame rate: Main stream: 3840×2160@(1–20 fps) / 2688×1520@(1–25/30 fps); Sub stream: 704×576@(1–25 fps) / 704×480@(1–30 fps)
• Resolution options: 8M, 6M, 5M, 4M, 3M, 1080p, 1.3M, 720p, D1, VGA, CIF
• Bit rate control: CBR/VBR
• Video bit rate: H.264: 32–8192 kbps; H.265: 12–8192 kbps
• Default bit rate and resolution: 6144 kbps (3840 × 2160)
• Day/Night mode: Auto(ICR)/Color/B&W
• BLC: Yes
• HLC: Yes
• WDR: DWDR
• White balance: Auto; Natural; Street lamp; Outdoor; Manual; Regional
• Gain control: Auto/Manual
• Noise reduction: 3D NR
• Motion detection: On/Off (4 areas, rectangular)
• Regions of interest (RoI): Yes (4 areas)
• Smart illumination: Yes
• Image rotation: 0°/90°/180°/270° (90°/270° for ≤2688×1520)
• Mirror: Yes
• Privacy masks: 4 areas
• Languages: English; Russian; Spanish
• Alarm events: Network disconnection; IP conflict; unauthorized access; motion detection; tampering; audio detection; SMD (human); exception
• Network port: RJ-45 (10/100 Base-T)
• SDK and API: Yes
• Network protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P
• Compatibility: ONVIF (Profile S and T); CGI
• Users/Hosts: 6 (total 48 Mb/s)
• Data storage: FTP
• Browsers: IE; Chrome; Firefox
• Management software: Smart PSS Lite; DSS; DMSS; DoLynk Care
• Mobile app: iOS; Android
• Security: Video/config encryption; Digest; WSSE; account lock; logs; X.509; HTTPS; trusted boot/execution/update
• Operating temperature: –40 °C to +60 °C
• Operating humidity: ≤95% (non-condensing)
• Storage temperature: –40 °C to +60 °C
• Storage humidity: ≤95% (non-condensing)
• Protection degree: IP67
• Lens type: Fixed focal
• Lens mount: M12
• Focal length: 3.6 mm
• Maximum aperture: F1.6
• Angle of view: H: 86°; V: 49°; D: 100°
• Aperture control: Fixed
• Image settings: Brightness; Contrast; Sharpness; Saturation; Gamma
• OSD overlays: Time; channel; location; custom overlay
• Recording modes: Manual recording; detection recording; schedule recording; alarm recording. Priority: Manual > Detection > Schedule
• Default settings: One-click restore to default settings
• User management: Up to 20 users
• Security: Username and password; MAC address; HTTPS; network access control
• Low-light sensitivity: Starlight
• Human detection (intelligent): Supports classification and accurate human detection
• Intelligent search: Works with Smart NVR for intelligent search, extraction and merging of events with recordings
