Eaton 217219 contatto ausiliario 1 N/O montaggio frontale morsetti a vite per contattori DILM7-DILM32

The Eaton 217219 auxiliary contact stands out with its front mounting design, enabling quick installation without removing the contactor. It adds a single normally open (N/O) contact to Eaton DILM7–DILM32 contactors, expanding control possibilities in industrial setups.

Highlights

• 1 N/O instantaneous auxiliary contact
• Front mounting for easy access
• Screw terminals for secure wiring
• Compatible with Eaton DILM7 to DILM32 contactors
• Rated for up to 4 A at 230–400 V AC and 10 A at 24 V DC

In daily use

This auxiliary contact integrates seamlessly into control circuits, providing reliable status feedback or interlocking functions. Its compact design and straightforward screw connections make it a practical choice for panel builders and maintenance technicians.

Full specifications

• Contact configuration: 1 N/O (Normally Open)
• Mounting type: Front mounting
• Terminal type: Screw terminals
• Compatibility: Eaton DILM7 to DILM32 contactors
• Rated operational current (AC-15, 230 V): 4 A
• Rated operational current (AC-15, 400 V): 4 A
• Rated operational current (DC-13, 24 V): 10 A
• Rated operational current (DC-13, 110 V): 3 A
• Rated insulation voltage (Ui): 690 V
• Rated impulse withstand voltage (Uimp): 6 kV
• Degree of protection: IP20
• Operating temperature range: -25 to +60 °C
• Standards: IEC/EN 60947-5-1
• Number of auxiliary contacts: 1
• Auxiliary contact type: Instantaneous
• Connection capacity (solid/stranded): 0.75 - 2.5 mm²
• Connection capacity (fine-strand with ferrule): 0.75 - 1.5 mm²
• Series: DILM

Final note

A dependable auxiliary contact for expanding the functionality of Eaton DILM contactors.
