Guida per rack 19 pollici Roadinger Effektrack Studio 48,30 cm — guide di montaggio 1U per effetti e apparecchiature rack

Roadinger Effektrack Studio 48.30 cm is a pair of 19-inch rack mounting rails designed to provide stable 1U mounting points for effects units and compact rack devices. Made for standard studio racks, the rails simplify installation and organization of audio processors, pedals in rack housings, and other low-profile equipment commonly used in professional and project studio environments.

Advantages

The rails offer a precise 19" spacing and rigid 1U support to secure devices reliably while minimizing vibration and movement. Constructed to match standard rack dimensions, the set enables straightforward alignment and repeatable mounting positions. The compact design preserves usable rack space and allows tidy cable routing behind mounted units.

Suitable for

Key specifications

How to use

Install the rails into the front upright posts of a standard 19" rack by aligning the mounting holes with the rack’s threaded inserts or cage nuts. Secure each rail with suitable rack screws at the appropriate vertical position for 1U mounting. Slide or place the device into the 1U location and fasten the device to the rails using the appropriate screws. Ensure cables are routed and secured behind the mounted device to prevent strain on connectors.

Recommendations

Check that rack screw types and thread patterns match your cabinet (threaded inserts or cage nuts) and use appropriate screw lengths to avoid contact with internal components. For heavier devices, use additional mounting points or supplemental support to distribute load and reduce stress on the front rail.
