Hirschmann HIT AUKAB 440/200 cavo coassiale 4,4 m bianco

The Hirschmann HIT AUKAB 440/200 is a high-quality coaxial cable designed for reliable signal transmission in TV, radio, DVB-T, and DVB-C applications. With a length of 4.4 meters and double shielding, it ensures excellent screening attenuation and minimal interference.

Advantages

This cable features oxygen-free copper (OFC) inner conductor and aluminum foil plus copper braid outer conductor for superior conductivity and shielding. The foamed polyethylene dielectric and PVC jacket provide durability and flexibility. With 75 Ohm impedance and frequency range up to 1000 MHz, it delivers clear signal quality.

Suitable for

• TV and radio connections
• DVB-T and DVB-C digital broadcasting
• Satellite and cable TV installations

Key specifications

• Cable Type: Coaxial Cable
• Length: 4.4 m
• Connector A: IEC Coaxial Male
• Connector B: IEC Coaxial Female
• Impedance: 75 Ohm
• Shielding: Double Shielded
• Inner Conductor: Oxygen-Free Copper (OFC)
• Outer Conductor: Aluminum Foil + Copper Braid
• Jacket Material: PVC
• Colour: White
• Frequency Range: 5 - 1000 MHz
• Screening Attenuation: >90 dB (30-1000 MHz)
• Attenuation (860 MHz): ~20 dB/100m
• Dielectric: Foamed Polyethylene (PE)
• Outer Diameter: Approx. 6.5 mm
• Return Loss: >20 dB
• Operating Temperature: -5°C to +50°C

Recommendations

For optimal performance, use with compatible IEC connectors and ensure proper termination. Ideal for home entertainment and professional AV setups.
