HP SMPS-V2 M4075FX/XRX PSPN2-TYPE2-V2 A Fly

Delivering up to 300W across +24V, +12V, +5V, and +3.3V rails, this HP SMPS-V2 power supply keeps the LaserJet M4075 series running at peak performance. Engineered for the M4075FX and M4075XRX models, it converts 100-240V AC input into stable DC output with over 80% efficiency.

Overview

The HP SMPS-V2 M4075FX/XRX PSPN2-TYPE2-V2 A Fly is a proprietary switched-mode power supply designed specifically for HP LaserJet M4075 series printers. Revision V2 brings refined power delivery and enhanced protection features. It mounts internally via screw-in chassis design and includes an integrated fan for active cooling.

What stands out

• High efficiency: >80% conversion reduces energy waste and heat.
• Multiple output rails: +24V (8A), +12V (5A), +5V (10A), +3.3V (8A) for all printer subsystems.
• Comprehensive protection: OVP, OCP, and SCP safeguard the printer and PSU.
• Long lifespan: MTBF over 100,000 hours ensures years of reliable service.
• Certified: CE, FCC, and RoHS compliant for safety and environmental standards.

Technical details

• Input: 100-240V AC, 50/60 Hz
• Max output power: 300W
• Output rails: +24V/8A, +12V/5A, +5V/10A, +3.3V/8A
• Form factor: Proprietary for HP M4075 series
• Connectors: Proprietary multi-pin mainboard connector and auxiliary power connectors
• Cooling: Integrated fan
• Operating temperature: 0°C to 40°C (32°F to 104°F)
• Protection: Over Voltage, Over Current, Short Circuit
• MTBF: >100,000 hours
• Certifications: CE, FCC, RoHS

Our verdict

A genuine HP power supply built for the M4075 series, delivering stable, efficient power with robust protection. The V2 revision ensures compatibility and reliability for high-volume printing environments.
