OBO V-TEC VM25 LGR pressacavo metrico M25 poliammide grigio chiaro RAL 7035

Ensuring reliable cable entry and strain relief in demanding industrial environments can be a challenge, especially when space is tight and protection requirements are high. The OBO V-TEC VM25 LGR cable gland solves this by offering a compact, halogen-free solution for metric M25 knockouts, combining robust sealing with easy installation.

Who is it for

This cable gland is ideal for electricians, panel builders, and maintenance technicians working with control cabinets, machinery, or outdoor installations. It suits applications where cables with diameters from 9 to 17 mm must be securely routed through enclosures while maintaining IP68 protection against dust and water immersion.

Main features

• Metric M25 thread with 10 mm thread length for standard knockouts
• Lamellar strain relief technology provides excellent cable retention without damaging the jacket
• IP68 protection up to 5 bar pressure, suitable for temporary submersion
• Halogen-free polyamide (PA) body, light grey RAL 7035, UV-resistant for outdoor use
• Wide operating temperature range from -20 °C to +100 °C
• EPDM sealing ring ensures a tight seal on various cable types
• Impact resistance rated IK08, flammability UL94 V-2
• Approvals: VDE, UL, CSA, GL, DNV

Specifications

• Thread type: Metric
• Thread size: M25
• Material: Polyamide (PA)
• Colour: Light grey (RAL 7035)
• Protection class: IP68 (up to 5 bar)
• Cable clamping range: 9 - 17 mm
• Wrench size: 30 mm
• Thread length: 10 mm
• Operating temperature: -20 to +100 °C
• Halogen-free: Yes
• UV-resistant: Yes
• Seal material: EPDM
• Impact resistance: IK08
• Flammability rating: UL94 V-2
• Standards/Approvals: VDE, UL, CSA, GL, DNV
• Strain relief type: Lamellar technology

Tips

For optimal sealing, ensure the cable outer diameter falls within the specified clamping range and tighten the gland to the recommended torque. When used outdoors, the UV-resistant material prevents degradation, but regular inspection of the seal is advised in harsh environments. Pair with OBO V-TEC locknuts for secure mounting.
