RAIJINTEK METIS PLUS case Mini Tower PC rosso — Mini-ITX, 1x vano 3,5 pollici, 4x vani 2,5 pollici, ventola 120 mm

RAIJINTEK METIS PLUS is a compact Mini-ITX aluminium mini tower case in red. The upgraded METIS design combines a hairline-anodized aluminium finish with support for standard ATX power supplies, a 170 mm graphics card and a 160 mm CPU cooler height, while keeping a small footprint (190 × 277 × 254 mm) and a lightweight construction (2.12 kg). The case includes one pre-installed 120 mm rear O-type LED fan, space for an optional top 120 mm fan, a transparent side window and front I/O with two USB 3.2 Gen 1 Type‑A ports.

Advantages

The METIS PLUS offers a solid aluminium build that improves heat dissipation and keeps the case lightweight. It supports a full-size ATX power supply and relatively long graphics cards (up to 170 mm), providing flexibility in component choice for a Mini-ITX system. Storage options include one 3.5" bay plus four 2.5" bays for combined HDD and SSD configurations. The pre-installed rear 120 mm O-type LED fan and option for a top fan help maintain airflow in the compact interior.

Suitable for

• Compact Mini-ITX gaming or productivity PCs with discrete GPU up to 170 mm
• Small form-factor home or office systems using one 3.5" HDD and multiple 2.5" SSDs
• Systems requiring a standard ATX power supply in a small aluminium chassis

Key specifications

• Form factor: Mini Tower, supports Mini-ITX motherboards
• Dimensions: 190 × 277 × 254 mm
• Weight: 2.12 kg
• Material: Aluminium, hair-silk anodized finish (red)
• Drive bays: 1 × 3.5", 4 × 2.5"
• Expansion: Supports VGA cards up to 170 mm
• CPU cooler clearance: up to 160 mm
• Fans: 1 × 120 mm rear O-type LED (pre-installed), 1 × 120 mm top (optional)
• I/O: 2 × USB 3.2 Gen 1 (Type-A)
• Power supply: supports standard/regular ATX PSU (not included)
• Side window: yes

How to use

Install a Mini-ITX motherboard and mount storage drives in the provided 3.5" and 2.5" bays. Fit a standard ATX power supply in the PSU area and connect power cables to the motherboard and drives. Install a graphics card up to 170 mm if required and a CPU cooler with a maximum height of 160 mm. Connect the front-panel USB ports to the motherboard headers. Verify fan orientation and connect the pre-installed rear 120 mm fan, and optionally install a 120 mm top fan to improve airflow.

Recommendations

For best thermal performance in this compact aluminium case, use a low-profile CPU cooler within the 160 mm clearance, ensure good cable management to avoid blocking airflow, and consider adding the optional top 120 mm fan when using a discrete GPU or high-power components.
