Supermicro RSC-W-66G5 riser card PCIe 5.0 x16 2 slot per server 2U

The Supermicro RSC-W-66G5 is a high-performance PCIe 5.0 riser card designed for Supermicro 2U server chassis. It provides two PCIe 5.0 x16 slots via a right-angle edge connector, enabling expansion with GPUs, NVMe SSDs, network cards, and other add-on cards. This riser card supports data transfer rates up to 128 GB/s per slot and is compatible with Supermicro X13 and H13 series platforms.

Advantages

Maximizes PCIe expansion in 2U servers with two full-height, full-length slots. PCIe 5.0 ensures future-proof bandwidth for demanding workloads. Plug-and-play installation simplifies deployment in compatible Supermicro systems.

Suitable for

• Supermicro 2U server chassis (X13, H13 series)
• Adding GPUs for AI/ML or rendering
• NVMe SSD storage expansion
• High-speed networking (100GbE/200GbE)

Key specifications

• Product Type: Riser Card
• PCI Express Generation: PCIe 5.0
• Number of PCIe Slots: 2
• PCIe Slot Configuration: 2x PCIe 5.0 x16
• Form Factor: 2U Server Riser
• Motherboard Connector: PCIe x16 (Edge Connector)
• Expansion Card Connector: 2x PCIe x16 Slots
• Orientation: Right-angle
• Data Transfer Rate: Up to 128 GB/s (per slot)
• Power Source: PCIe Slot Power
• Material: PCB with gold-plated connectors
• Installation: Plug-and-play

Recommendations

Ensure your Supermicro server chassis and motherboard support PCIe 5.0 and the riser slot configuration. For optimal performance, use PCIe 5.0 compatible add-on cards.
