Switch KVM Digitus DS-72212 porta singola

The DIGITUS DS-72212 modular KVM switch is a single-port unit designed for flexible server-farm administration. It supports USB and PS/2 keyboard and mouse connections and provides VGA video output. The compact 1U-compatible, space-saving casing allows easy integration into server racks and can be combined with DIGITUS 17" or 19" modular consoles, a keyboard and the required cable set for operation.

Advantages

The modular design enables individual configuration, upgrade and conversion with additional modules, providing longer-term investment protection. The unit supports local connection of a server via USB or PS/2 and VGA. Optional high-quality KVM switch modules with IP functionality are available to enable remote browser-based access over an existing network. The compact weight and standard console port (DB-25) make it simple to install and integrate into existing setups.

Suitable for

• Small to mid-sized server rooms
• Server racks requiring 1U-compatible space-saving components
• Environments needing local or (with optional IP module) remote console access
• Setups using USB or PS/2 keyboards and mice with VGA video

Key specifications

• Manufacturer: DIGITUS
• Model: DS-72212
• Ports: single server port (console port DB-25)
• Keyboard/Mouse: USB and PS/2 support
• Video output: VGA
• Product colour: Black
• Weight: 0.18 kg
• Form factor: 1U-compatible, space-saving casing
• MPN: DS-72212
• EAN: 4016032447573

How to use

Install the DS-72212 into the appropriate rack position or place it near the console; connect the console via the DB-25 console port using the required cable set. Attach the server to the unit using USB or PS/2 connections for keyboard and mouse and connect VGA for video. If remote access is required, install the optional IP-capable KVM module following the module instructions and configure network settings to enable browser-based connections.

Recommendations

Use the DS-72212 together with a compatible DIGITUS 17" or 19" modular console, the matching keyboard and the correct cable set. For remote management, choose the optional IP module and ensure network security settings are applied according to your IT policies.
