Testina di stampa TSC 98-0470074-01LF 300 dpi

Replacement printhead with 12 dots/mm (300 dpi) resolution compatible with TSC TTP-346MT and other compatible TSC label printers. The TSC 98-0470074-01LF printhead is designed to restore print quality for barcodes, text and graphics in industrial and office labeling applications, providing consistent 300-dpi output for accurate, readable labels.

Advantages

The TSC 98-0470074-01LF delivers fixed 300 dpi resolution for sharp barcode and text reproduction, supports reliable printing performance to reduce misprints, and is a direct-fit replacement that simplifies maintenance and minimizes downtime in labeling and ticketing workflows.

Suitable for

• Industrial and office label printing
• Barcode and ticket printing
• Maintenance and replacement of TTP-346MT printheads

Key specifications

• Model: 98-0470074-01LF
• Resolution: 12 dots/mm (300 dpi)
• Compatibility: TSC TTP-346MT and compatible TSC printers
• Brand: TSC
• EAN: 5712505606131

How to use

Power off the printer and follow the manufacturer’s service manual to remove the old printhead. Install the TSC 98-0470074-01LF in the correct orientation, secure connectors and fasteners, then power on the printer. Perform any required printhead alignment and calibration using the printer’s maintenance menu or utility software to ensure optimal 300-dpi print quality.

Recommendations

Use genuine or manufacturer-recommended cleaning supplies and follow scheduled maintenance intervals to prolong printhead life. Replace the printhead when print quality degrades despite cleaning, and always handle the element by its edges to avoid damaging the thermal surface.
