TRACOPOWER TPC 030-112 Alimentatore per guida DIN, 30 W, 12 VDC, 2,5 A

DIN rail power supply delivering 30 W at 12 VDC with 2.5 A output current. Accepts universal AC input from 85 to 264 VAC and DC input from 90 to 375 VDC, with 87% typical efficiency. Features short circuit, overload, and overvoltage protection, 3000 VAC input-to-output isolation, and 100 mVp-p maximum ripple and noise. Operating temperature range from -20°C to +70°C, MTBF over 300,000 hours, and plastic housing for DIN rail mounting.

Advantages

Wide input voltage range allows use in various industrial environments. High isolation voltage ensures safety and noise immunity. Compact plastic housing saves space on the DIN rail. High MTBF indicates long-term reliability.

Suitable for

• Industrial automation systems
• Building control panels
• Machinery requiring 12 VDC supply
• Distributed power architectures

Key specifications

• Output: 12 VDC, 2.5 A, 30 W
• Input: 85-264 VAC, 90-375 VDC
• Efficiency: 87%
• Isolation: 3000 VAC
• Operating temperature: -20°C to +70°C
• MTBF: >300,000 hours

Recommendations

For reliable DIN rail power in industrial settings, the TPC 030-112 offers a balance of performance and durability.
