Yato YT-1763 martinetto idraulico 10 tonnellate

The Yato YT-1763 is a hydraulic bottle jack with a 10-ton lifting capacity, built for vehicle repair and industrial lifting tasks. Its robust high-strength steel construction and integrated overload valve provide reliable performance and safety under load.

Advantages

The jack features a two-piece pumping handle for efficient operation and an adjustable screw extension that adds 60 mm to the lifting range. The cast iron base ensures stability, while the red finish offers visibility in the workshop.

Suitable for

• Lifting vehicles during repair and maintenance
• Workshop and industrial applications
• Use with jack stands for additional safety

Key specifications

• Lifting capacity: 10 Ton (10,000 kg)
• Minimum height: 200 mm
• Maximum height: 385 mm
• Hydraulic lift range: 125 mm
• Adjustable screw extension: 60 mm
• Base dimensions: 115 x 100 mm
• Material: High-strength steel
• Safety feature: Integrated overload valve
• Handle type: Two-piece pumping handle
• Operating temperature range: -20°C to +50°C
• Jack type: Hydraulic Bottle Jack
• Construction: Robust cast iron base

Recommendations

Always use jack stands when working under a lifted vehicle. Do not exceed the rated capacity.
