YDYp Cavo piatto 4x1,5mm² 450/750V bianco 100m

The YDYp flat power cable is designed for fixed installation in dry and damp locations, suitable for surface or recessed mounting. With 4 solid copper conductors of 1.5 mm² cross-section, it provides reliable power distribution for residential and commercial applications. Rated voltage 450/750V, PVC insulation and sheath, white colour, length 100m.

Advantages

Solid copper conductors ensure low resistance and stable current transmission. Flat shape allows space-saving installation. PVC sheath provides good mechanical protection and flexibility. Complies with PN-EN 50575 and PN-HD 21.4 S2 standards.

Suitable for

• Fixed electrical installations in buildings
• Surface or recessed mounting in dry and damp rooms
• Power supply for lighting, sockets, and appliances

Key specifications

• Cable type: YDYp
• Conductor material: Copper, solid
• Number of conductors: 4
• Cross-section: 1.5 mm²
• Rated voltage: 450/750 V
• Insulation: PVC
• Sheath: PVC
• Shape: Flat
• Colour: White
• Length: 100 m
• Max conductor temperature: +70°C
• Operating temperature: -30°C to +70°C
• CPR class: Eca
• Outer dimensions: approx. 5.5 x 10.5 mm
• Packaging: Coil/Reel

Recommendations

For indoor fixed installations. Ensure compliance with local electrical codes. Use appropriate connectors and junction boxes.
