2-power 2P-B116XTN02.3-HW2B - display - 29,5 cm (11,6") - WXGA

Replace a cracked or faulty screen in a compact laptop with this 11.6-inch WXGA display panel from 2-POWER. Technicians and DIY upgraders working on ultraportable notebooks will appreciate the straightforward 30-pin eDP connection and the matte TN surface that keeps reflections low in bright offices or on the go.

Key specifications

• Screen size: 11.6 inches (29.5 cm)
• Native resolution: 1366 x 768 (WXGA)
• Aspect ratio: 16:9
• Panel type: TN (Twisted Nematic)
• Backlight: LED
• Surface finish: Matte
• Connector: 30-pin eDP (Embedded DisplayPort)
• Refresh rate: 60 Hz
• Response time: 8 ms (typical)
• Viewing angles: 45/45/20/40 degrees (L/R/U/D)
• Color support: 262,144 colors (6-bit)

Why choose it

This panel delivers crisp text and accurate colors for everyday productivity, streaming, and web browsing. The LED backlight ensures consistent brightness and energy efficiency, while the matte coating reduces glare under fluorescent lights or near windows. Its universal design fits a wide range of compatible laptops, making it a practical choice for repairs and upgrades.

Ideal use cases

• Replacing a broken or dim laptop screen
• Upgrading an older panel to LED backlighting
• Building or repairing a portable workstation
• Restoring a secondary travel laptop

Good to know

The 30-pin eDP connector is standard on many modern ultrabooks and netbooks. Before ordering, verify that your device supports a 1366 x 768 WXGA resolution and a 30-pin eDP interface. Installation requires careful handling of the LCD and cable; professional installation is recommended for those unfamiliar with laptop disassembly.
