2-power 2P-FSP036-RHAN2 - 12 V - 35 mm - 88 mm - 26 mm - 266 g - 128 mm

When space is tight but dependable backup power is non-negotiable, the 2-Power 2P-FSP036-RHAN2 delivers a compact 12V sealed lead acid solution that punches above its 1.2Ah rating. Unlike generic batteries that fade after a few dozen cycles, this VRLA unit is engineered for float service in security panels, UPS units and emergency lighting, holding a steady charge for 3–5 years with zero maintenance.

Highlights

• 12V 1.2Ah capacity with F1 (Faston Tab 187) terminals for easy connection
• Valve Regulated Lead Acid (VRLA) technology – totally spill-proof and leak-proof
• Maintenance-free, no watering or acid checks required
• Wide operating temperature range from -15°C to 50°C (discharge)
• CE, ISO9001 and ISO14001 certified for quality and environmental management
• Compact footprint: 35mm deep × 88mm wide × 26mm high, weighs only 266g

In daily use

Install the 2P-FSP036-RHAN2 in an alarm panel, access control box or small UPS and it sits quietly in float charge, ready to take over the instant mains power drops. The 18A maximum discharge current (5-second pulse) is enough to trigger locks, sounders or emergency lamps without voltage sag. Because the case is sealed and the electrolyte is immobilised, you can mount it in any orientation except inverted – ideal for cramped enclosures.

Full specifications

• Brand: 2-Power
• Model: 2P-FSP036-RHAN2
• MPN: 2P-FSP036-RHAN2
• Battery type: Sealed Lead Acid (SLA)
• Technology: VRLA (Valve Regulated Lead Acid)
• Voltage: 12 V
• Capacity: 1.2 Ah
• Terminal type: F1 (Faston Tab 187)
• Rechargeable: Yes
• Maintenance-free: Yes
• Design: Spill-proof, leak-proof
• Expected lifespan (float): 3–5 years
• Operating temperature (discharge): -15°C to 50°C
• Operating temperature (charge): -15°C to 40°C
• Operating temperature (storage): -15°C to 40°C
• Internal resistance: approx. 100 mΩ
• Max. discharge current (5 sec.): 18 A
• Float charging voltage: 13.5–13.8 V @ 25°C
• Cycle charging voltage: 14.4–15.0 V @ 25°C
• Primary application: UPS systems, alarm systems, emergency lighting
• Secondary application: medical equipment, toys, general purpose
• Certifications: CE, ISO9001, ISO14001
• Dimensions (D × W × H): 35 mm × 88 mm × 26 mm
• Weight: 266 g

Final note

For installers and OEMs who need a reliable, certification-backed SLA battery in a truly compact form factor, the 2P-FSP036-RHAN2 is a drop-in upgrade that won't leak, won't need service and won't let you down when the power fails.
