Adattatore di cablaggio MITEL 415/430 TS1 (modello 20350370) per connessioni a centralini telefonici

Wiring adapter MITEL 415/430 TS1 (model 20350370) is an accessory created to connect and adapt telephone wiring for Mitel 415 and 430 systems. It provides a TS1 interface to ensure correct signal routing and secure cable termination, simplifying installation, maintenance and rewiring tasks in office telephony and PBX environments. The adapter is intended for inline connection between station wiring and the Mitel system backplane, offering a compact solution for reliably joining multiple conductors and maintaining signal integrity during routine changes or relocations.

Advantages

The adapter ensures consistent electrical contacts and reduces installation time by providing a standardized TS1 interface compatible with Mitel 415 and 430 equipment. Its design supports organized cable termination, improving accessibility for maintenance and minimizing the risk of faulty connections. The compact form factor facilitates installation in racks or communication cabinets without requiring additional adapters or complex tools.

Suitable for

• Connecting station wiring to Mitel 415 and 430 PBX systems
• Office telephony installation and rewiring tasks
• Maintenance and testing of telephone line terminations
• Relocation of desk phones and short-term cabling changes

Key specifications

• Interface type: TS1 wiring interface for Mitel 415/430 systems
• Function: Signal routing and secure cable termination
• Compatibility: Designed for Mitel 415 and Mitel 430 telephone systems
• Form factor: Compact inline adapter suitable for racks and cabinets
• Connection: Multi-conductor termination suitable for standard telephone wiring

How to use

Install the adapter between the incoming station wiring and the Mitel 415 or 430 system TS1 connection point, following the system wiring diagram and safety procedures. Ensure all conductors are correctly aligned with the adapter's termination points and that secure contact is achieved before powering the system. During installation, verify continuity and correct pair assignments with appropriate test equipment and, if necessary, label terminated pairs to simplify future maintenance.

Recommendations

Use the adapter in dry, dust-free communication cabinets and avoid exposing termination points to excessive mechanical stress. For reliable operation, perform continuity tests after installation and keep a record of wiring changes to support future troubleshooting and system audits.
