ALLNET adattatore antenna SMA femmina a SMA maschio (ANT-ADP-SMAF-SMAM)

The ALLNET ANT-ADP-SMAF-SMAM is a high-quality coaxial RF adapter designed to connect SMA female connectors to SMA male connectors. Ideal for WLAN, Wi-Fi, and RF systems, this adapter ensures reliable signal transmission with minimal loss. Its robust construction features a brass body with nickel plating and gold-plated center contacts for durability and optimal performance.

Advantages

This adapter offers a straight orientation and supports a wide frequency range from DC to 6 GHz, making it versatile for various applications. With a low VSWR of less than 1.2:1 and insertion loss below 0.1 dB, it maintains signal integrity. The PTFE dielectric material ensures stable performance across temperatures from -40°C to +85°C.

Suitable for

• WLAN and Wi-Fi antenna connections
• RF systems and test equipment
• Extending or adapting SMA cables

Key specifications

• Connector Type: SMA Female to SMA Male
• Impedance: 50 Ohm
• Frequency Range: DC - 6 GHz
• Body Material: Brass, Nickel Plated
• Center Contact: Brass/Beryllium Copper, Gold Plated
• Dielectric: PTFE
• VSWR: < 1.2:1
• Insertion Loss: < 0.1 dB
• Operating Temperature: -40°C to +85°C
• Durability: 500 mating cycles
• RoHS Compliant

Recommendations

For optimal performance, use with 50 Ohm SMA cables and connectors. Ensure proper mating to maintain low VSWR.
