BlueLAN compatibile Molex 747521208 cavo Direct Attach SFP+ su SFP+ passivo 10GBASE-CR, 2 m, AWG30

The BlueLAN compatible Molex 747521208 10GBASE-CR passive SFP+ to SFP+ direct attach cable (DAC) is a high-performance, cost-effective solution for short-range 10 Gigabit Ethernet connections in data centers, server-to-switch, and storage area networks. This 2-meter cable features AWG30 wire gauge and is fully compliant with SFF-8431 and SFF-8472 standards, ensuring reliable operation and interoperability with SFP+ MSA compliant equipment.

Advantages

This passive DAC cable offers low power consumption (<0.1W per end), hot-swappable convenience, and robust PVC jacket material for durability. It supports Ethernet, Fibre Channel, and InfiniBand protocols, making it versatile for various network environments. The cable is RoHS compliant and operates in temperatures from 0°C to 70°C.

Suitable for

• Data center interconnects
• Server-to-switch connections
• Storage Area Networks (SAN)
• High-performance computing clusters

Key specifications

• Product Type: Direct Attach Cable (DAC)
• Cable Type: SFP+ to SFP+
• Data Rate: 10 Gigabit Ethernet (10GbE)
• Technology Standard: 10GBASE-CR
• Cable Length: 2 Meter
• Wire Gauge: AWG30
• Cable Design: Passive
• Connector Type: SFP+
• Compatibility: Molex 747521208 compatible, SFP+ MSA compliant
• Impedance: 100 Ohm
• Compliance: SFF-8431, SFF-8472
• Hot-Swappable: Yes
• Power Consumption: < 0.1W (per end)
• Operating Temperature: 0°C to 70°C (32°F to 158°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Jacket Material: PVC
• RoHS Compliant: Yes

Recommendations

For optimal performance, ensure that both connected devices support SFP+ MSA and 10GBASE-CR standard. This cable is ideal for short-distance, high-speed links within racks or adjacent racks.
