Busch-Jaeger 1713-914 scatola da parete, 3 posti, forma alta, bianco alpino

For installations where flush-mount enclosures demand deep wall cavities, the Busch-Jaeger 1713-914 surface-mount box offers a high-profile alternative that stands proud of the wall, ready for retrofit and exposed-wire installations. Its three-gang layout provides generous space for combining switches, sockets, and dimmers from compatible Busch-Jaeger ranges, while the halogen-free thermoplastic housing in Alpine White keeps the installation both safe and visually neutral.

Highlights

• 3-gang surface-mount enclosure for versatile electrical combinations
• High-profile design accommodates deeper inserts and simplifies wiring
• Halogen-free thermoplastic construction for enhanced safety
• Pre-punched knock-outs for flexible cable entry from top, bottom, or rear
• Compatible with Busch-Jaeger switch ranges: future® linear, carat®, solo®, Busch-Duro 2000® SI/SI Linear
• IP20 rating for indoor use
• Alpine White colour for a clean, modern look

In daily use

Installing the 1713-914 is straightforward: the surface-mount design eliminates the need for deep wall cavities, making it ideal for solid walls, historic buildings, or temporary installations. Electricians will appreciate the generous internal volume, which reduces strain on wiring and allows neat routing of conductors. The knock-outs are positioned to support top, bottom, or rear cable entry, and the high-profile form factor means even deeper inserts fit without compromise.

Full specifications

• Enclosure type: Surface-mount box
• Number of gangs: 3
• Mounting method: Surface-mounted
• Design version: High profile
• Material: Thermoplastic
• Colour: Alpine White
• IP protection rating: IP20
• Halogen-free: Yes
• Compatibility: Busch-Jaeger switch ranges (future® linear, carat®, solo®, Busch-Duro 2000® SI/SI Linear)
• Application: For housing electrical inserts like switches, sockets, and dimmers
• Installation environment: Indoor use only
• Cable entry: Pre-punched knock-outs for top, bottom, or rear entry

Final note

A practical solution for surface-mounted electrical installations, combining flexibility, safety, and a clean aesthetic.
