BUSCH-JAEGER meccanismo deviatore doppio 2601/5/20 EAPBJ-522 (2TKA00005539)

The BUSCH-JAEGER 2601/5/20 is a flush-mounted double two-way switch insert that controls two independent circuits from a single rocker position. Unlike single-function inserts, it combines two switching mechanisms in one compact unit, making it a practical choice for lighting control in residential and commercial installations where space and wiring simplicity matter.

Highlights

• Double two-way switching for two separate circuits
• Rated 10 AX at 250 V AC for demanding loads
• Screw terminals accept rigid conductors from 1.5 to 2.5 mm²
• Halogen-free thermoplastic construction
• Compatible with Busch-Jaeger rocker covers and frames

In daily use

This insert is installed behind a compatible Busch-Jaeger rocker cover and frame. Each of the two rockers switches its own circuit, allowing independent control of two light groups from one location. The screw terminals provide a secure connection, and the insert is designed for flush mounting in standard wall boxes.

Full specifications

• Type: Double two-way switch insert
• Switching function: Two independent two-way circuits
• Rated voltage: 250 V AC
• Rated current: 10 AX
• Connection type: Screw terminals
• Terminal capacity: 1.5–2.5 mm² (rigid conductors)
• Mounting type: Flush-mounted
• Material: Thermoplastic, halogen-free
• Protection class: IP20
• Operating temperature: -5 to +40 °C
• Storage temperature: -20 to +70 °C
• Manufacturer series: Universal for various Busch-Jaeger switch ranges
• ABB type designation: 2601/5/20
• ABB order code: 2TKA00005539

Final note

The 2601/5/20 insert is a reliable core component for building custom switch combinations with Busch-Jaeger cover plates and frames.
