Case per PC Thermaltake View 170 TG ARGB Snow micro tower bianco

The View 170 TG ARGB Snow Micro Chassis features tempered glass panels on the front and left side to showcase internal components. Designed for micro-ATX (M-ATX) builds, it supports up to three pre-installed 120mm ARGB Lite fans, top radiator mounting up to 280mm, and storage options for two 2.5" SSDs plus one 3.5" HDD. The case includes convenient top I/O with two USB 3.0 ports and an HD audio jack, and it can synchronize lighting with compatible motherboard RGB software.

Advantages

The tempered glass front and side panels provide wide viewing angles for a clean presentation of hardware. Pre-installed ARGB Lite fans deliver immediate illumination and can be controlled through common motherboard software, eliminating the need for separate controllers. Support for a 280mm top radiator and multiple fan mounts enables flexible cooling configurations within a compact M-ATX chassis. Top-mounted I/O ports offer easy access for peripherals and audio.

Key specifications

• Form factor: Micro ATX (M-ATX) compatible
• Panels: Tempered glass front and left side
• Pre-installed fans: Three 120mm ARGB Lite (rear and side)
• Radiator support: Up to 280mm on top
• Storage: Up to two 2.5" SSDs and one 3.5" HDD
• I/O ports: 2 × USB 3.0, 1 × HD audio
• RGB compatibility: ASUS Aura Sync, GIGABYTE RGB Fusion, MSI Mystic Light Sync, ASRock Polychrome (requires 5V addressable RGB header)

How to use

Install an M-ATX motherboard and connect the three pre-installed 120mm ARGB Lite fans to the motherboard 5V addressable RGB header and fan headers according to the motherboard manual. Mount a top radiator up to 280mm if required, ensuring clearance for other components. Install storage drives in the designated 2.5" and 3.5" locations and connect power and data cables. Use the top-panel USB 3.0 ports and HD audio jack for peripherals and headset connections.

Recommendations

For ARGB lighting control, use motherboard software that supports 5V addressable RGB headers (ASUS Aura Sync, GIGABYTE RGB Fusion, MSI Mystic Light Sync, ASRock Polychrome). Verify radiator clearance and fan placement for optimal airflow in M-ATX builds.
