Cavo di alimentazione Bachmann 304.276 bianco 5 m

The Bachmann 304.276 power cable is a 5 m mains lead designed for use with equipment requiring up to 250 V and 16 A. The cable is finished in white and combines a moulded right-angle plug with a dual earthing contact system at one end and a 30 mm stripped conductor end with end sleeves at the other, providing a straightforward connection option for installation or repair tasks.

Advantages

The moulded right-angle plug reduces strain at the connector and saves space behind devices. The dual earthing contact system ensures a reliable protective earth connection. A 30 mm stripped end with end sleeves gives a ready-prepared conductor for secure termination. The 5 m length offers flexibility for positioning equipment while the white colour blends with modern interiors.

Suitable for

• Powering office equipment and appliances up to 250 V / 16 A
• Replacement mains lead for compatible devices
• Electrical installations where a stripped conductor end is required for wiring
• Situations needing a right-angle plug to save space behind equipment

Key specifications

• Manufacturer: Bachmann
• Model / MPN: 304.276
• EAN: 4016514002252
• Cable length: 5 m
• Rated voltage: 250 V
• Rated current: 16 A
• Colour: White
• End 1: moulded right-angle plug with dual earthing contact
• End 2: 30 mm stripped conductors with end sleeves

How to use

Connect the moulded right-angle plug to the equipment or mains outlet, ensuring the plug is compatible with local socket types. Use the stripped 30 mm conductor end with end sleeves to terminate the cable into terminal blocks, connectors or a distribution unit according to the device wiring diagram. Make all connections with the mains supply switched off and follow applicable wiring codes and safety procedures.

Recommendations

Use the cable within its rated limits of 250 V and 16 A. Avoid sharp bends near the plug and secure the stripped end under appropriate terminals to prevent loosening. For fixed installations or where additional mechanical protection is required, consider using conduit or cable clips. If unsure about wiring or compliance, consult a qualified electrician.
