Cisco gruppo cavi a bassa perdita 10ft con connettori N

In wireless installations, signal loss over cable runs can severely degrade performance, causing dropped connections and reduced range. This 10-foot low loss cable assembly with N connectors directly addresses that issue, delivering minimal attenuation for reliable RF transmission in Wi-Fi, cellular, and other RF systems.

Who is it for

Network engineers, system integrators, and IT professionals who need to connect antennas to access points, routers, or other RF equipment with minimal signal degradation. Ideal for outdoor and indoor wireless deployments where cable length is moderate but performance is critical.

Main features

• Low loss LL195 cable type ensures strong signal integrity over the 10-foot length.
• N-Male connectors on both ends provide secure, weather-resistant connections for outdoor use.
• 50 Ohm impedance matches standard RF equipment for optimal power transfer.
• Double shielding (aluminum tape + tinned copper braid) reduces interference and signal leakage.
• Wide frequency range from DC to 6 GHz supports Wi-Fi, cellular, GPS, and more.
• Durable black polyethylene jacket withstands harsh environments and UV exposure.
• RoHS compliant for environmental safety.

Specifications

• Cable type: LL195 low loss
• Length: 10 ft (3.05 m)
• Connectors: N-Male to N-Male
• Impedance: 50 Ohm
• Frequency range: DC to 6 GHz
• Attenuation: 1.7 dB @ 900 MHz, 2.7 dB @ 2.4 GHz, 4.0 dB @ 5.8 GHz
• VSWR: < 1.3:1
• Jacket material: Polyethylene (PE), black
• Outer diameter: 0.195 in (4.95 mm)
• Center conductor: Solid bare copper
• Dielectric: Foamed polyethylene
• Shielding: Double (aluminum tape + tinned copper braid)
• Operating temperature: -40°C to +85°C
• Max power handling: 200 W @ 900 MHz
• RoHS compliant

Tips

For best performance, ensure connectors are properly tightened and weatherproofed when used outdoors. Avoid sharp bends that could damage the cable or alter impedance. This cable is ideal for short antenna runs where low loss is essential.
