Connettore maschio di rete C14 Bachmann 915.171 nero

For connecting cables up to 3G 1.00 mm², this thermoplastic junction connector features an integrated earthing contact C14 and is designed for secure cable splicing. The compact module provides electrical continuity for live, neutral and earth conductors in small installations and repair situations.

Advantages

The thermoplastic housing ensures insulating protection and durability while keeping weight low. An integrated earthing contact C14 provides reliable protective earth connection. The connector includes a screw terminal for secure conductor fixation, a kink protection nozzle to prevent cable bending at the entry point, and a strain relief to reduce mechanical stress on the conductors.

Key specifications

• Suitable conductor size: up to 3G 1.00 mm²
• Material: thermoplastic housing
• Earthing contact: C14
• Terminal type: screw terminal
• Cable protection: kink protection nozzle
• Mechanical protection: integrated strain relief

How to use

Strip the cable conductors to the recommended length, insert each conductor into the corresponding screw terminal and tighten the screws to secure electrical contact. Position the cable through the kink protection nozzle to prevent sharp bending and engage the strain relief to fix the cable housing and reduce mechanical load on the conductors. Verify continuity and correct earthing before energizing the circuit.

Recommendations

Use this connector only with cables and installations that match the specified conductor size (up to 3G 1.00 mm²) and follow local electrical codes. If unsure about installation or earthing requirements, consult a qualified electrician.
