Convertitore DC/DC ATTE ASUC-100-AD0-OF 100W 12V 8,3A Guida DIN

The ATTE ASUC-100-AD0-OF is a high-efficiency, non-isolated DC/DC step-up converter in an open frame (OF) design. It offers a wide input voltage range and precise output voltage adjustment, making it suitable for generating PoE 48 VDC from 12 VDC or 24 VDC supplied by a buffer power supply.

Key features

• Wide input voltage range
• Precise output voltage adjustment over a wide range
• Low heat generation due to high efficiency
• High output power in a compact module size
• Reverse polarity protection
• Open Frame (OF) construction for integration into any enclosure
• Mounting via snap-on distance pins and mounting holes with 10.8 mm grid
• LED1 operation indicator: output voltage present

Specifications

• Brand: ATTE
• MPN: ASUC-100-AD0-OF
• Output voltage: 12...48 VDC
• Output power: 120W @24V, 80W @12V
• Efficiency: 93% @Vin=12V, Pout=80W
• Input voltage range: 10...30 VDC
• No-load current: 27mA @12V
• Operating temperature range: -20...+40°C
• Dimensions: 40 x 83 x 27 mm
• Weight: 0.036 kg
