COREPARTS MBXLDAD-BA010 batteria sigillata al piombo-acido 12V 7Ah AGM connettore F1

Power interruptions and unreliable backup energy can cripple critical systems—from security alarms to medical devices. The COREPARTS MBXLDAD-BA010 sealed lead acid battery delivers dependable 12V 7Ah capacity with AGM technology, ensuring your equipment stays operational when mains power fails. Its maintenance-free, spill-proof design makes it a safe, long-lasting choice for a wide range of applications.

Who is it for

This battery is ideal for integrators, facility managers, and DIY users who need a robust power source for UPS units, emergency lighting, security systems, medical devices, and toys. It suits anyone requiring a reliable, rechargeable SLA battery that fits standard F1 terminal connections.

Main features

• 12V nominal voltage and 7Ah capacity (20-hour rate) for consistent performance
• AGM (Absorbent Glass Mat) technology with valve-regulated, spill-proof construction
• Maintenance-free operation—no need to check or refill electrolyte
• F1 (Faston Tab 187) terminals for easy connection in many devices
• Wide operating temperature range: discharge from -15°C to 50°C, charge from -15°C to 40°C
• Low self-discharge rate (<3% per month at 20°C) for extended shelf life
• Durable ABS case (UL94 HB) with a design life of 3-5 years under standard commercial use
• Can be mounted in any orientation except continuous inverted

Specifications

• Voltage: 12 V
• Capacity: 7 Ah (20-hour rate)
• Battery technology: Sealed Lead Acid (SLA) / AGM
• Terminal type: F1 (Faston Tab 187)
• Float charge voltage: 13.5 - 13.8 VDC (at 20°C)
• Cycle charge voltage: 14.4 - 15.0 VDC (at 20°C)
• Max discharge current (5 sec): 105 A
• Internal resistance: approx. 25 mΩ
• Self-discharge rate: <3% per month at 20°C
• Operating temperature (discharge): -15°C to 50°C
• Operating temperature (charge): -15°C to 40°C
• Case material: ABS (UL94 HB)
• Maintenance type: maintenance-free
• Rechargeable: yes
• Mounting orientation: any (except continuous inverted)

Tips

For optimal lifespan, store the battery at 20°C and recharge every 6 months if unused. Always use a charger with the correct float voltage (13.5-13.8V) to prevent overcharging. Ensure terminals are clean and connections are tight to avoid power loss.
