DEANTE ADI D911 Inserto da Incasso Bianco Doppia Presa Schuko con Protezione Bambini

The DEANTE ADI D911 Wall Cup is a high-quality flush-mounted double Schuko socket outlet designed for safe and reliable power distribution in residential and commercial environments. Manufactured by DEANTE, this wall cup features integrated child protection shutters and is made from durable, fire-resistant PC/ABS plastic. It is part of the Simon Basic series and requires a separate frame for installation.

Advantages

This wall cup offers enhanced safety with built-in child protection, UV and fire resistance, and compliance with CE and PN-EN 60669-1 standards. Its flush-mount design ensures a clean, professional finish, and the screw terminals provide secure and easy wiring.

Suitable for

• Residential wall installations
• Commercial office spaces
• Retail and hospitality environments
• Any standard double flush box with 60mm spacing

Key specifications

• Socket Type: Double Schuko (Type F) with earthing pin
• Rated Voltage: 250V AC
• Rated Current: 16A
• Mounting Type: Flush-mounted
• IP Rating: IP20
• Material: High-quality PC/ABS plastic
• Colour: White
• Number of Modules: 2
• Terminal Type: Screw terminals
• Connection Type: 2P+E (Two Poles + Earth)
• Standards: CE, PN-EN 60669-1
• Frame Included: No (requires separate frame)
• UV Resistance: Yes
• Fire Resistance: Yes (self-extinguishing materials)
• Installation Box Compatibility: Standard double flush box (60mm spacing)

Recommendations

For optimal installation, use a compatible double flush box and a separate frame from the Simon Basic series. Ensure proper grounding and follow local electrical codes.
