DEHN 377006 nastro per equipotenzialità, alluminio, 170 mm, 25 mm²

Aluminum equipotential bonding strap with 25 mm² cross-section and 170 mm length, compliant with DIN EN 62561-1. Designed for reliable, corrosion-resistant connections in lightning protection and earthing systems.

Overview

The DEHN 377006 is a flat aluminum strap engineered for equipotential bonding applications. Its 25 mm² conductor cross-section ensures low impedance, while the 170 mm length provides flexibility in installation. The strap features two bolt connection points with 10.5 mm holes for M10 bolts, enabling secure attachment.

What stands out

• High corrosion resistance and UV resistance for long-term outdoor use
• Wide operating temperature range from -40 °C to +80 °C
• Natural aluminum finish for durability without additional coating
• Compliant with DIN EN 62561-1 for lightning protection components

Technical details

• Material: Aluminum (Al)
• Conductor cross-section: 25 mm²
• Length: 170 mm
• Connection type: Bolt connection
• Bolt hole diameter: 10.5 mm (for M10 bolts)
• Number of connection points: 2
• Design: Flat strap
• Surface finish: Natural Aluminum
• UV resistance: Yes
• Operating temperature range: -40 °C to +80 °C
• Standard compliance: DIN EN 62561-1
• Installation environment: Indoor, Outdoor

Our verdict

The DEHN 377006 bonding strap delivers robust performance in demanding environments. Its aluminum construction and compliance with key standards make it a reliable choice for professional lightning protection and earthing installations.
