Dell docking station Thunderbolt WD19TBS (N9CJV)

Drive up to three displays at 4K 60Hz and charge your laptop at 130W with this Thunderbolt 3 docking station.

Overview

The Dell WD19TBS is a Thunderbolt 3 docking station that turns a single USB-C port into a full desktop workstation. It supports up to three external displays, delivers up to 130W of power to Dell laptops, and provides high-speed data transfer at up to 40Gbps.

What stands out

• Supports up to three displays: 2x DisplayPort 1.4 and 1x HDMI 2.0b, plus USB-C DisplayPort Alt Mode.
• Power Delivery up to 130W for Dell systems, 90W for non-Dell systems.
• Thunderbolt 3 host interface with 40Gbps data transfer rate.
• Multiple USB ports: 3x USB 3.1 Gen 1 Type-A, 2x USB 3.1 Gen 2 Type-C (one with PowerShare).
• Gigabit Ethernet, audio combo jack, and security lock slots.

Technical details

• Host Interface: Thunderbolt 3 (USB-C)
• Video Ports: 2 x DisplayPort 1.4, 1 x HDMI 2.0b, 1 x USB-C (DisplayPort Alt Mode)
• USB-A Ports: 3 x USB 3.1 Gen 1
• USB-C Ports: 2 x USB 3.1 Gen 2 (1 with PowerShare)
• Ethernet Port: 1 x Gigabit Ethernet (RJ-45)
• Audio Ports: 1 x Headphone/Speaker combo, 1 x Audio output
• Max External Displays Supported: 3
• Max Resolution (Single Display): 5120 x 2880 @ 60Hz
• Max Resolution (Dual Displays): 2 x 3840 x 2160 @ 60Hz
• Power Delivery to Host: Up to 130W (Dell systems), 90W (non-Dell systems)
• Power Adapter Included: 180W AC Adapter
• Thunderbolt Cable Length: 0.8 meters
• Data Transfer Rate: Up to 40 Gbps
• Security Features: Kensington Lock Slot, Noble Wedge Lock Slot
• Operating System Support: Windows 10/11, Ubuntu, RedHat
• Advanced Features: PXE Boot, Wake-on-LAN, MAC Address Pass-Through

Our verdict

The Dell WD19TBS is a powerful docking solution for professionals who need multi-display support and high-speed connectivity. Its Thunderbolt 3 interface ensures future-proof performance for demanding workflows.
