EATON FAZT-B13/1 Interruttore automatico magnetotermico 13A 1 polo curva B 6kA 240793

Protect electrical circuits from overload and short circuit with the EATON FAZT-B13/1 miniature circuit breaker. This 1-pole MCB is rated at 13 A with a B tripping characteristic, making it ideal for residential and commercial installations where moderate inrush currents are expected. It mounts on a standard DIN rail and provides reliable switching capacity up to 6 kA.

Who is it for

Electricians, panel builders, and facility managers who need a dependable circuit protection device for lighting and socket circuits in distribution boards.

Main features

• 13 A rated current, 1-pole
• B tripping characteristic for standard loads
• 6 kA rated switching capacity
• DIN rail mounting, 1 module width (17.5 mm)
• Operating temperature -25 to +75 °C

Specifications

• Rated voltage: 230/400 V AC
• Frequency: 50/60 Hz
• Energy limitation class: 3
• Terminal capacity: 1-25 mm²
• Degree of protection: IP20 (terminals), IP40 (front)

Tips

Ensure the MCB's rated current and tripping characteristic match the load profile of the circuit. For circuits with high inrush currents (e.g., motors, transformers), consider a C or D characteristic breaker.
