EFB U-DQ(ZN)BH OM4 24G (2x12) Eca 3000N LSZH nero 8mm

The EFB U-DQ(ZN)BH OM4 24G (2x12) Eca 3000N LSZH Black 8mm is a high-performance loose tube fiber optic cable designed for universal indoor/outdoor applications. With 24 multimode fibers arranged in 2 tubes of 12, this cable delivers exceptional bandwidth and low attenuation for demanding network infrastructures.

Advantages

This cable offers a robust 3000N maximum tensile strength, ensuring durability during installation and operation. The LSZH (Low Smoke Zero Halogen) sheath provides enhanced safety in confined spaces by emitting minimal smoke and no toxic halogens in case of fire. The Eca fire performance class complies with European CPR standards, making it suitable for commercial and residential buildings.

Suitable for

• Data center backbone cabling
• LAN and SAN networks
• Indoor/outdoor campus and building riser applications
• High-speed fiber-to-the-desk (FTTD) installations

Key specifications

• Fiber Type: OM4 Multimode (50/125 μm)
• Number of Fibers: 24 (2 tubes x 12 fibers)
• Cable Construction: Loose tube, non-metallic (Aramid yarns)
• Outer Diameter: 8 mm
• Sheath Material: LSZH, black
• Maximum Tensile Strength: 3000 N
• Fire Performance: Eca (EN 50575)
• Attenuation: ≤ 3.0 dB/km @ 850 nm, ≤ 1.0 dB/km @ 1300 nm
• Bandwidth: 4700 MHz·km (OFL) / 3500 MHz·km (EMB) @ 850 nm; 500 MHz·km (OFL) @ 1300 nm
• Operating Temperature: -20°C to +70°C
• Minimum Bending Radius (Static): 80 mm (10 x OD)

Recommendations

For optimal performance, pair this cable with OM4-compatible connectors (LC, SC, etc.) and ensure proper strain relief during installation. Suitable for use in structured cabling systems requiring high bandwidth and future-proofing for 40G/100G Ethernet.
