Equip 235211 scatola da parete 1 porta Cat.6

The equip® 1-Port Cat.6 Surface Mount Box (model 235211) provides a single RJ45 port for Cat.6 network connections in a compact white housing. Designed for easy, tool-free installation, the package includes one adhesive tape strip and the unit measures 39 mm (W) x 29.5 mm (D) x 54 mm (H). Its compact size and simple mounting make it suitable for home and office network extensions where a discrete surface-mounted outlet is required.

Advantages

The surface mount box supports a Cat.6 RJ45 connection in a small, low-profile enclosure and is supplied with adhesive tape to enable quick, tool-free installation. Its white finish blends with most interiors and the lightweight design simplifies handling and placement.

Suitable for

• Adding a single Cat.6 network outlet on walls or other flat surfaces
• Temporary or permanent network points in homes and small offices
• Locations where in-wall cabling or socket replacement is impractical

Key specifications

• Model: Equip 235211
• Port: 1 × RJ45 (Cat.6)
• Colour: White
• Dimensions: 39 mm × 29.5 mm × 54 mm (W × D × H)
• Package dimensions: 175 mm × 65 mm × 100 mm
• Weight: 0.04 kg

How to use

Clean the mounting surface, remove the protective film from the included adhesive tape, and press the surface mount box firmly onto the chosen flat surface. Connect the Cat.6 cable to the RJ45 socket according to standard wiring practices. Ensure the cable is secured and routed to avoid strain on the port. No additional tools are required for mounting with the supplied tape; use screws (not included) if a more permanent fixing is desired.

Recommendations

The adhesive mounting is suitable for smooth, clean surfaces; avoid mounting on textured, damp, or dusty surfaces. For long-term installations or where mechanical stress is expected, use screws or alternative fixings in addition to or instead of the adhesive tape.
