EUROLITE SAB-62X distributore di corrente trifase 19 pollici 2U con 6 prese Schuko, ingresso CEE 16A, 11kW 60003755

The EUROLITE SAB-62X stands out among 19-inch power distributors with its robust 3-phase input and six individually protected Schuko outlets, delivering up to 11 kW of clean, reliable power for professional stage, studio, and event installations. Unlike basic power strips, this 2U rack-mount unit features a CEE 16A 5-pin plug and three 16A circuit breakers—one per phase—ensuring safe load distribution and quick recovery from overloads. Its steel housing and integrated 1.5 m cable make it a dependable backbone for demanding AV racks.

Highlights

• 3-phase 400 V AC input via CEE 16A 5-pin plug (1.5 m cable included)
• 6 Schuko (Type F) outlets, each phase protected by a 16 A circuit breaker
• High total capacity: 48 A / 11.04 kW (3.68 kW per phase)
• Compact 2U rack-mount form factor for 19" installations
• Durable black steel housing, ideal for touring and fixed setups

In daily use

Mount the SAB-62X in any standard 19" rack and connect your equipment with confidence. The three-phase design balances loads across phases, reducing the risk of tripping a single breaker when powering amplifiers, moving heads, or LED walls. The front-facing Schuko sockets allow easy access, while the rear CEE input keeps cabling tidy. Should an overload occur, only the affected phase trips, leaving the rest of your rig running—a critical advantage during live events.

Full specifications

• Input connector: 1x CEE 16A 5-pin plug (3-phase, 400 V AC, 50 Hz)
• Output connectors: 6x Schuko sockets (Type F, 230 V per phase)
• Maximum total current: 48 A (16 A per phase)
• Maximum total power: 11040 W (11.04 kW)
• Maximum power per phase: 3680 W (3.68 kW)
• Protection: 3x 16 A circuit breakers (one per phase)
• Mounting: 19-inch rack, 2U height
• Integrated cable length: 1.5 m
• Housing material: Steel
• Colour: Black
• Application: Professional audio, lighting, stage, studio, event technology

Final note

For installers and rental companies needing a reliable, high-capacity power distribution solution, the EUROLITE SAB-62X delivers industrial-grade performance in a compact 2U package—built to handle the demands of modern production environments.
