EVOLIS Trade-up CP XXS -> ID-ALL

The Evolis IDALL-TUXXSE1 Trade-up CP XXS to ID-ALL transforms your existing Evolis CP XXS printer into the powerful ID-ALL model, unlocking dual-sided printing, enhanced speed, and advanced security features. This upgrade kit is the smart choice for organizations that need high-volume, secure card issuance without investing in a completely new system.

Highlights

• Dual-sided printing with automatic flip for efficient card personalization
• Fast print speeds: up to 170 color cards/hour duplex, 850 monochrome cards/hour simplex
• 300 dpi resolution for crisp text, barcodes, and images
• Modular encoding options: magnetic stripe, contact and contactless smart cards
• Advanced security: Kineclipse® data obscuration, digital erasing, UV printing, optional locking system
• Broad card compatibility: PVC, composite PVC, PET, ABS, varnished cards, thickness 0.25–1.25 mm

In daily use

With the ID-ALL upgrade, your card production becomes significantly more efficient. The 100-card input and output hoppers reduce manual intervention, while the dual-sided printing capability eliminates the need for manual card flipping. The printer handles a wide range of card materials and thicknesses, making it suitable for employee badges, student IDs, membership cards, and more. Connectivity via USB 2.0 or Ethernet allows easy integration into your existing network, and the Evolis Premium Suite® software provides intuitive design and management tools for Windows, macOS, and Linux environments.

Full specifications

• Print technology: Direct-to-card dye-sublimation/resin thermal transfer
• Print mode: Dual-sided (automatic flip)
• Print resolution: 300 dpi
• Print speed (color YMCKO, duplex): 170 cards/hour
• Print speed (monochrome, simplex): 850 cards/hour
• Input hopper capacity: 100 cards (0.76 mm / 30 mil)
• Output hopper capacity: 100 cards (0.76 mm / 30 mil)
• Card thickness: 0.25 to 1.25 mm (10 to 50 mil)
• Card types: PVC, composite PVC, PET, ABS, special varnished cards
• Card format: ISO CR80 (85.6 x 54 mm / 3.375" x 2.125")
• Connectivity: USB 2.0 (compatible 3.0), Ethernet TCP-IP (10/100 Mbit)
• Memory: 32 MB RAM
• Encoding options (modular): Magnetic stripe, contact smart card, contactless smart card
• Security features: Kineclipse® (data obscuration), digital erasing, UV printing, optional locking system
• Software: Evolis Premium Suite® for Windows, Mac driver, Linux driver, SDK
• OS support: Windows 7/8/10/11, macOS 10.13+, Linux
• Power supply: 100-240 Volts AC, 50-60 Hz
• Warranty: 3 years (printer and print head)

Final note

Upgrade to the Evolis ID-ALL and experience professional-grade card printing with the reliability and security your organization demands.
