EXSYS EX-1344HMV hub USB 2.0 industriale a 4 porte, metallo, montaggio su guida DIN/parete, 7-24V DC, protezione ESD e sovratensione

Industrial-grade USB 2.0 hub with four downstream USB Type-A ports and one upstream USB Type-B port, engineered for harsh environments. Its all-metal housing, wide operating temperature range, and robust ESD and surge protection make it ideal for factory automation, kiosks, and embedded systems.

Advantages

Built to last with a rugged metal enclosure and 15KV air / 8KV contact ESD protection. Supports DIN-rail and wall mounting for flexible installation. Wide 7-24V DC power input via terminal block or DC jack ensures compatibility with industrial power systems.

Suitable for

• Industrial automation and control cabinets
• Digital signage and kiosk systems
• Embedded PCs and machine vision
• Harsh environments with temperature extremes

Key specifications

• USB 2.0 High-Speed, up to 480 Mbps
• 4 x USB Type-A downstream ports
• 1 x USB Type-B upstream port
• Metal housing, DIN-rail / wall mountable
• Power input: 7-24V DC (terminal block or DC jack)
• ESD protection: 15KV air, 8KV contact
• Surge protection: 600W per port
• Operating temperature: -40°C to +85°C
• Chipset: Genesys Logic GL850G
• LED indicators: power and port status
• Overcurrent protection per port
• Compatible with Windows, macOS, Linux

Recommendations

For reliable USB expansion in demanding industrial settings, the EX-1344HMV offers the durability and protection needed for continuous operation.
