EXSYS EX-3455 Scheda controller RAID 2-Port SATA III 6Gbps PCIe 2.0 x1 (RAID 0/1, ASMedia ASM1061, Low Profile)

Add two SATA 6Gbps ports with hardware RAID 0/1 to any PCIe 2.0 x1 slot. The EXSYS EX-3455 delivers up to 600 MB/s per port, hot-swap support, and bootable capability for Windows, Linux, and macOS.

Overview

The EXSYS EX-3455 is a 2-port SATA III RAID controller card based on the ASMedia ASM1061 chipset. It provides two internal SATA 6Gb/s ports, supporting RAID 0, RAID 1, JBOD, and AHCI modes. The card fits a PCI Express 2.0 x1 slot and includes a low-profile bracket for small form factor systems.

What stands out

• Two SATA 6Gbps ports with up to 600 MB/s per port
• Hardware RAID 0 and RAID 1 for performance or data mirroring
• PCIe 2.0 x1 interface, compatible with x4, x8, x16 slots
• Hot-swap support and bootable capability
• Low-profile bracket included for slim desktops

Technical details

• Host interface: PCI Express 2.0 x1
• Internal ports: 2 x SATA 6Gb/s
• Data transfer rate: 6 Gbps (600 MB/s) per port
• RAID levels: 0, 1, JBOD, AHCI
• Chipset: ASMedia ASM1061
• Operating systems: Windows XP/Vista/7/8/10/11, Linux, macOS
• Form factor: Plug-in card, low profile bracket included

Our verdict

A reliable and compact SATA III RAID controller for expanding storage with speed and redundancy.
