Finder 41.61.9.024.0010 relè di potenza PCB 24 VDC 1 CO 16 A

In industrial control cabinets and building automation panels, the Finder 41.61.9.024.0010 PCB power relay switches loads up to 16 A with a 24 VDC coil. Its compact footprint and reinforced insulation make it a reliable choice for dense PCB layouts.

Key specifications

• Coil voltage: 24 VDC
• Coil power: 400 mW
• Contact configuration: 1 CO (SPDT)
• Rated contact current: 16 A
• Rated contact voltage: 250 VAC
• Contact material: AgNi
• Dielectric strength coil-contact: 5 kV (1.2/50 µs)
• Dielectric strength open contacts: 1000 VAC
• Insulation: Reinforced
• Operating temperature: -40 to +85 °C
• Protection degree: RT II (flux proof)
• Electrical life: 100,000 operations
• Mechanical life: 10,000,000 operations
• Terminal type: PCB pins
• Series: Finder 41

Why choose it

The relay's reinforced insulation and 5 kV impulse withstand voltage provide safe isolation between coil and contacts, meeting stringent safety requirements. Its flux-proof construction protects against solder flux and contaminants during PCB assembly.

Ideal use cases

• Programmable logic controllers (PLCs)
• HVAC control systems
• Industrial automation
• Appliance control boards
• Power supplies

Good to know

This relay is part of the Finder 41 series, known for its compact size and high switching capacity. It is suitable for PCB mounting and offers reliable performance in demanding environments.
