GETAC Antenna esterna

With a GPS gain of 28 ± 2 dBi via an integrated LNA, this external antenna dramatically boosts positioning accuracy for Getac rugged devices in challenging environments. The Getac 590GBL000238 is a multi-band external antenna engineered for permanent vehicle mounting, combining GPS, 4G LTE, and Wi-Fi coverage in a single rugged housing. It is the ideal connectivity upgrade for field professionals who demand reliable navigation, cellular, and wireless data in remote or mobile operations.

Overview

The Getac 590GBL000238 external antenna is a high-performance, IP67-rated solution designed specifically for Getac rugged laptops, tablets, and convertibles. It supports GPS L1 (1575.42 MHz), WWAN/LTE (698-960 MHz and 1710-2700 MHz), and WLAN/Wi-Fi (2.4-2.5 GHz and 4.9-5.85 GHz) frequencies, ensuring seamless connectivity across critical bands. With three separate SMA/RP-SMA connectors and 3-meter cables, installation is straightforward and flexible for a variety of vehicle setups. The antenna's vertical polarization and UV-resistant ABS housing guarantee long-term durability in harsh outdoor conditions.

What stands out

• Exceptional GPS sensitivity with 28 ± 2 dBi LNA gain for precise location tracking even in urban canyons or dense foliage.
• Tri-band coverage (GPS, LTE, Wi-Fi) eliminates the need for multiple antennas, reducing clutter and installation complexity.
• Rugged IP67-rated construction withstands dust, water, and extreme temperatures from -40°C to +85°C.
• Permanent screw mount design ensures stable, vibration-resistant attachment for vehicle fleets.
• Compatible with a wide range of Getac rugged devices, making it a versatile accessory for mixed fleets.

Technical details

• Antenna Type: Multi-Band External
• Mounting Type: Permanent Screw Mount (Vehicle)
• Frequency Bands: GPS 1575.42 MHz; WWAN 698-960 MHz, 1710-2700 MHz; WLAN 2.4-2.5 GHz, 4.9-5.85 GHz
• Gain: GPS 28 ± 2 dBi (LNA), WWAN 3 dBi, WLAN 5 dBi
• Impedance: 50 Ohm
• VSWR: < 2.0:1
• Connectors: 1x SMA Male (GPS), 1x SMA Male (WWAN), 1x RP-SMA Male (WLAN)
• Cable Length: 3 meters per cable
• Polarization: Vertical
• Housing Material: UV-resistant ABS
• IP Rating: IP67
• Operating Temperature: -40°C to +85°C
• Compatibility: Getac Rugged Laptops, Tablets, Convertibles
• Application: Enhanced GPS, Cellular (4G LTE), and Wi-Fi connectivity for vehicle integration
• Colour: Black

Our verdict

For Getac users who need uncompromising connectivity on the move, the 590GBL000238 is a top-tier choice. Its high-gain GPS, broad frequency support, and rugged build make it a reliable companion for field service, public safety, and logistics. The straightforward installation and proven compatibility ensure it integrates seamlessly into existing Getac deployments.
