Gira Presa SCHUKO con caricabatterie USB Type-C PD, 16 A, da parete, bianca 236300

This SCHUKO socket outlet insert combines a standard Type F power socket with a USB Type C charging port, delivering power and device charging from a single flush-mounted unit. The integrated USB-C port supports Power Delivery for fast charging of compatible smartphones, tablets, and other USB-C devices.

Advantages

The insert fits standard flush-mounted boxes and is compatible with Gira System 55, E2, Event, Esprit, Standard 55, and F100 design lines, allowing integration with existing switch ranges. Screw terminals accept rigid conductors up to 2.5 mm², and the halogen-free thermoplastic housing supports sustainable installations.

Suitable for

• Residential and commercial flush-mounted installations
• Charging USB-C devices directly at the wall socket
• Use with Gira cover frames from System 55, E2, Event, Esprit, Standard 55, and F100

Key specifications

• Socket type: SCHUKO (Type F) with earth contact
• USB port: Type C with Power Delivery
• Rated current: 16 A
• Rated voltage: 250 V AC
• Frequency: 50/60 Hz
• Connection: screw terminals, max 2.5 mm² rigid
• Material: halogen-free thermoplastic
• Protection class: IP20
• Operating temperature: -5 to +40 °C
• Installation depth: approx. 32 mm

Recommendations

Pair with a Gira cover frame from the System 55 or E2 range for a coordinated finish. Ensure the flush-mounted box has sufficient depth for the 32 mm insert.
