Gira System 3000 modulo di comando termostato ambiente, alluminio 536026

Managing room temperature precisely often requires a dedicated controller that blends with modern interiors. The Gira System 3000 operating attachment offers intuitive push-button control and a clear segment display for heating and cooling systems, housed in a sleek aluminium faceplate.

Who is it for

This attachment suits homeowners and building managers using the Gira System 3000 platform who need a reliable, wall-mounted temperature controller with a premium metal finish. It integrates with Gira System 55 and compatible design lines, making it a natural choice for both new installations and retrofits.

Main features

• Controls heating and cooling with automatic, manual, and frost protection modes
• Segment display with backlight for clear readability
• Weekly program, timer function, and holiday function for flexible scheduling
• Internal temperature sensor with setting range from +5 °C to +30 °C
• Aluminium faceplate, lacquered, with 55 x 55 mm visible area
• Key lock and valve protection function for safety and maintenance
• Optimized heating/cooling start and automatic summer/winter time changeover

Specifications

• Product type: Room temperature controller operating attachment
• System compatibility: Gira System 3000
• Design line compatibility: Gira System 55, E2, Event, Esprit, ClassiX
• Display: Segment display with backlight
• Material: Aluminium (lacquered)
• Colour: Aluminium
• Operating modes: Heating, cooling, automatic, manual, frost protection
• Programming: Weekly program, timer function, holiday function
• Temperature setting range: +5 °C to +30 °C
• Temperature sensor: Internal
• Control type: Push buttons
• Power supply: Via Gira System 3000 insert (e.g., heating control insert)
• Mounting: On Gira System 3000 insert (flush-mounted)
• Special features: Automatic summer/winter time changeover, key lock, valve protection, optimized start
• Protection class: IP20
• Visible area: 55 x 55 mm

Tips

Pair this attachment with a compatible Gira System 3000 insert for full functionality. The aluminium finish complements metallic switch ranges, and the backlit display remains legible in low light. Use the holiday function to reduce energy use while away.
