HAGER EGK100 Timer settimanale digitale con Bluetooth e montaggio su guida DIN

The HAGER EGK100 is a digital weekly time switch with Bluetooth connectivity, offering precise control of lighting and heating systems. Its standout feature is the ability to program up to 50 ON/OFF switching times via the Hager Mood app or directly on the device.

Advantages

This time switch provides flexible scheduling with manual override, holiday program, random function, and pulse function. Automatic summer/winter time changeover and a 5-year power reserve ensure reliable operation even after power outages.

Suitable for

• Controlling lighting circuits in residential and commercial buildings
• Managing heating and ventilation systems
• Automating electrical loads on a weekly schedule

Key specifications

• 1 channel (1 NO contact)
• Supply voltage: 230 V AC, 50/60 Hz
• Switching capacity: 16 A / 250 V AC resistive, 2000 W incandescent/halogen, 600 W LED
• Mounting: DIN rail, 2 modules wide
• Protection class: IP20
• Operating temperature: -20 to +55 °C
• Display: LCD
• Accuracy: ±1 s/day at 20 °C

Recommendations

For reliable weekly scheduling with remote access via Bluetooth, the HAGER EGK100 is a solid choice for electricians and facility managers.
