Hager RTQ106X Placca frontale citofono Mono 6 tasti bianco

The Hager RTQ106X is a modular front plate for mono intercom systems, offering six call buttons in a compact 106 x 106 mm format. Unlike single-button plates, this model enables visitor signaling to multiple apartments from one door station. The snap-in mounting and white thermoplastic construction simplify installation and blend with standard frames.

Highlights

• Six call buttons for multi-tenant door stations
• Mono intercom system compatibility
• Snap-in mounting for quick installation
• White thermoplastic body
• Part of the Hager RTQ modular series

In daily use

Mount the RTQ106X into a compatible Hager frame (flush or surface mounted, sold separately) and connect it to the mono intercom bus. Each button is labeled for a specific apartment; pressing a button triggers the corresponding indoor station's ringer. The IP20 rating suits sheltered outdoor locations or indoor entry areas.

Full specifications

• Product Type: Intercom Front Plate
• Number of Buttons: 6
• Intercom System Type: Mono
• Compatibility: Hager RTQ Intercom Systems
• Mounting Type: Requires separate flush-mounted or surface-mounted frame
• Material: Thermoplastic
• Color: White
• Design: Modular system component
• Function: Call button module for door stations
• Series: Hager RTQ
• Application: Door communication, visitor signaling
• Visible Dimensions (W x H): 106 x 106 mm
• Installation: Snap-in mounting
• IP Protection Class: IP20
• Operating Temperature: -5 to +45 °C

Final note

The RTQ106X front plate is a core component for building a multi-button door station with Hager RTQ intercoms. Pair it with the appropriate frame and audio module for a complete entry system.
