Hager SU213 campanello modulare 230V AC 0,03A 1 modulo guida DIN con suono continuo

In residential and light commercial electrical installations, a reliable audible signal for doorbells, buzzers, or alarm notifications is essential. The Hager SU213 modular bell provides a clear continuous tone at 80 dB, making it suitable for hallways, workshops, or offices where a distinct call signal is required. Designed for DIN rail mounting, it integrates seamlessly into distribution boards alongside other modular devices.

Key specifications

• Operating voltage: 230V AC, 50/60 Hz
• Rated current: 0.03 A
• Sound level: 80 dB at 1 metre
• Sound type: continuous tone
• Mounting: DIN rail (EN 60715), 1 module width (18 mm)
• Terminal capacity: 1.5 – 4 mm² (flexible or rigid conductors)
• Protection degree: IP20
• Operating temperature: -10 °C to +50 °C
• Storage temperature: -25 °C to +70 °C
• Rated insulation voltage: 250 V
• Rated impulse withstand voltage: 4 kV
• Housing material: thermoplastic
• Colour: light grey
• Connection: screw terminals
• Standards: EN 60669-1

Why choose it

The SU213 combines robust construction with straightforward installation. Its compact 1-module design saves space in the distribution board, while screw terminals ensure secure wiring. The continuous tone is easily distinguishable from other signals, reducing confusion in multi-occupancy buildings. Compliance with EN 60669-1 guarantees safety and performance.

Ideal use cases

• Doorbell signalling in residential flats and houses
• Audible alarm indication in small commercial premises
• Call notification in workshops or service areas
• Integration into existing 230V control circuits

Good to know

The bell is rated for indoor use only (IP20) and should be installed in a protected environment. It operates directly from the 230V mains without a transformer, simplifying wiring. For multiple bells or extended wiring runs, ensure the total current does not exceed the rated 0.03 A. The light grey housing blends with standard electrical panels.
