HARTING Han 3A RJ45 Cat. 6A modulo adattatore, 10 Gbit/s, schermato, nero

Experience 10 Gigabit Ethernet performance in industrial environments with the HARTING Han 3A RJ45 Adapter Module. This fully shielded Cat. 6A module delivers reliable high-speed data transmission up to 10 Gbit/s, making it ideal for demanding automation and data networks. The robust polycarbonate body and gold-plated copper alloy contacts ensure long-term durability, with a mating cycle rating of at least 500 operations.

Overview

The HARTING 09140009966 adapter module seamlessly integrates an RJ45 socket into the Han 3A modular connector system. Designed for snap-in mounting, it provides a secure and vibration-resistant connection for industrial Ethernet applications. The module meets IEC 60603-7-51 standards for Cat. 6A performance and supports Power over Ethernet (PoE) up to 100 W, enabling both data and power over a single cable.

What stands out

• 10 Gbit/s data rate for high-speed industrial networks
• Fully shielded RJ45 socket with 8P8C configuration
• Snap-in design for quick installation into Han 3A inserts
• Wide operating temperature range from -40°C to +70°C
• UL94 V-0 flammability rating for enhanced safety
• IP65/IP67 protection when mated with compatible housing

Technical details

• Connector type: RJ45 female (internal), Han 3A module interface (external)
• Ethernet category: Cat. 6A
• Maximum data transfer rate: 10 Gbit/s
• Shielding: Fully shielded
• Contact material: Copper alloy, gold plated
• Housing material: Polycarbonate (PC), black
• Mating cycles: ≥ 500
• Operating temperature: -40°C to +70°C
• Standards: IEC 60603-7-51
• Compatibility: HARTING Han 3A series housings

Our verdict

A robust and future-proof connectivity solution for industrial Ethernet, combining high-speed performance with rugged reliability in a compact form factor.
