HEINRICH KOPP Meccanismo pulsante per tapparella, bianco, 2 poli, 10A, 250V, da incasso 490452004

Controlling motorized blinds, shutters, or awnings often requires a dedicated switch that fits neatly into a standard wall box. The HEINRICH KOPP blind push-button switch insert provides a simple momentary up/down control in a compact, flush-mounted design. Its white thermoplastic housing blends with common switch ranges, and screw terminals ensure a secure connection.

Who is it for

Electricians and installers who need a reliable blind control insert for residential or commercial projects. It suits anyone replacing an existing blind switch or building a new control point, provided a compatible cover plate and frame are available.

Main features

• Momentary push-button control for up/down operation of blinds, shutters, and awnings.
• Flush-mounted insert fits standard wall boxes; cover plate and frame sold separately.
• Rated for 10 A at 250 V AC, suitable for typical motor loads.
• 2-pole switching with screw terminals for secure wiring.
• White thermoplastic housing, halogen-free.

Specifications

• Control type: Momentary push button
• Function: Up/down control
• Mounting type: Flush-mounted
• Rated current: 10 A
• Rated voltage: 250 V AC
• Number of poles: 2
• Connection type: Screw terminals
• Housing material: Thermoplastic
• Product colour: White
• Halogen-free: Yes
• Operating temperature: -5°C to +40°C

Tips

Verify the depth of your wall box and the compatibility of your chosen cover plate and frame before installation. For multi-location control, combine with additional inserts or a suitable blind control system.
