HellermannTyton 151-01188 Base di fissaggio avvitabile in poliammide nera per fascette, 28,6 mm, 200 pezzi

Cable tie mounting base for secure fastening of cable ties with a maximum width of 4.8 mm. This black base is made of polyamide 6.6 (PA66) and features a screw mount design for reliable attachment to surfaces. With a compact footprint of 28.6 x 28.6 mm and a height of 6.3 mm, it provides a low-profile anchoring point for cable management in various applications.

Advantages

The base is halogen-free and offers a wide operating temperature range from -40 °C to +85 °C, making it suitable for demanding environments. Its UL94 V2 flammability rating ensures a basic level of fire safety. The screw hole diameter of 4.3 mm accommodates M4 screws for easy installation.

Suitable for

• Securing cable ties in industrial control panels
• Organizing wiring harnesses in automotive and machinery
• General cable management in electrical installations

Key specifications

• Material: Polyamide 6.6 (PA66)
• Colour: Black
• Dimensions: 28.6 mm (L) x 28.6 mm (W) x 6.3 mm (H)
• Max. cable tie width: 4.8 mm
• Screw hole diameter: 4.3 mm (M4)
• Operating temperature: -40 °C to +85 °C
• Flammability rating: UL94 V2
• Halogen free: Yes
• Pack quantity: 200 pieces

Recommendations

For best results, use with HellermannTyton cable ties up to 4.8 mm width. Ensure the mounting surface is clean and use an M4 screw for secure attachment.
