HellermannTyton 712-00206 nastro isolante elettrico in PVC, nero, 19 mm x 20 m, 0,15 mm

This HellermannTyton PVC electrical insulation tape stands out for its reliable electrical insulation and mechanical protection in professional wiring tasks. The black tape has a width of 19 mm and a length of 20 m, with a thickness of 0.15 mm. It is made of polyvinyl chloride (PVC) with a rubber-based adhesive, providing good adhesion to steel and backing at 2.2 N/10mm. The tape is suitable for use in temperatures from -10 °C to +90 °C and offers good UV and weather resistance. It is self-extinguishing and meets IEC 60454-3-1 Type 5, VDE, and RoHS compliance.

Highlights

• PVC electrical insulation tape in black
• Dimensions: 19 mm width, 20 m length, 0.15 mm thickness
• Rubber-based adhesive with good adhesion
• Operating temperature range: -10 °C to +90 °C
• Good UV and weather resistance
• Self-extinguishing

In daily use

This tape is ideal for insulating electrical wires and cables, providing protection against moisture, abrasion, and UV exposure. Its flexibility and strong adhesive make it easy to apply and ensure a secure wrap. The black colour blends well in most installations.

Full specifications

• Material: Polyvinyl Chloride (PVC)
• Adhesive Type: Rubber-based
• Dielectric Strength: 6 kV
• Tensile Strength: 20 N/10mm
• Elongation at Break: 200%
• Voltage Rating: 600 V
• Adhesion to Steel: 2.2 N/10mm
• Adhesion to Backing: 2.2 N/10mm
• Standards: IEC 60454-3-1 Type 5, VDE, RoHS compliant

Final note

A dependable choice for professional electrical insulation, combining durability and safety.
